NFM21PC104R1E3D
| Part Number | NFM21PC104R1E3D |
| Manufacturer | Murata |
| Category | Filters |
| Description | CAP FEEDTHRU 0.1UF 20% 25V 0805 |
NFM21PC104R1E3D Specifications
| RoHS | No RoHS Information |
| EDA/CAD Models | NFM21PC104R1E3D PCB Footprint and Symbol |
| Brand | Murata |
| Product Line | Passive Components |
| Subcategory | Feed Through Capacitors |
| Series | EMIFIL®, NFM21 |
| Capacitance | 0.1µF |
| Tolerance | ±20% |
| Voltage - Rated | 25V |
| Current | 2A |
| DC Resistance (DCR) (Max) | 30 mOhm |
| Operating Temperature | -55°C ~ 125°C |
| Insertion Loss | - |
| Temperature Coefficient | - |
| Ratings | - |
| Mounting Type | Surface Mount |
| Package / Case | 0805 (2012 Metric), 3 PC Pad |
| Size / Dimension | 0.079" L x 0.049" W (2.00mm x 1.25mm) |
| Height (Max) | 0.037" (0.95mm) |
| Thread Size | - |
Quick Inquiry
| In Stock | 328626 - More on Order |
| Quote Limit | No Limit |
| Lead-Time | To be Confirmed |
| Minimum | 1 |
