| RoHS |
No RoHS Information
|
| EDA/CAD Models |
74HC4051D,653 PCB Footprint and Symbol |
| Warranty |
Up to 1 year [Limited-Warranty]* |
| Brand |
Nexperia |
| Product Line |
Semiconductors |
| Subcategory |
Analog Switches, Multiplexers, Demultiplexers |
| Series |
- |
| Switch Circuit |
- |
| Multiplexer/Demultiplexer Circuit |
8:1 |
| Number of Circuits |
1 |
| On-State Resistance (Max) |
120Ohm |
| Channel-to-Channel Matching (ΔRon) |
6Ohm |
| Voltage - Supply, Single (V+) |
2V ~ 10V |
| Voltage - Supply, Dual (V±) |
±1.5V ~ 5V |
| Switch Time (Ton, Toff) (Max) |
51ns, 42ns |
| -3db Bandwidth |
180MHz |
| Charge Injection |
- |
| Channel Capacitance (CS(off), CD(off)) |
3.5pF |
| Current - Leakage (IS(off)) (Max) |
400nA |
| Crosstalk |
- |
| Operating Temperature |
-40°C ~ 125°C (TA) |
| Package / Case |
16-SOIC (0.154", 3.90mm Width) |
| Supplier Device Package |
16-SO |
