BD809G
| Part Number | BD809G |
| Manufacturer | ON Semiconductor |
| Category | Transistors |
| Description | TRANS NPN 80V 10A TO-220AB |
BD809G Specifications
| RoHS | No RoHS Information |
| EDA/CAD Models | BD809G PCB Footprint and Symbol |
| Brand | ON Semiconductor |
| Product Line | Semiconductors |
| Subcategory | Bipolar (BJT) - Single |
| Series | - |
| Transistor Type | NPN |
| Current - Collector (Ic) (Max) | 10A |
| Voltage - Collector Emitter Breakdown (Max) | 80V |
| Vce Saturation (Max) @ Ib, Ic | 1.1V @ 300mA, 3A |
| Current - Collector Cutoff (Max) | 1mA (ICBO) |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 15 @ 4A, 2V |
| Power - Max | 90W |
| Frequency - Transition | 1.5MHz |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Mounting Type | Through Hole |
| Package / Case | TO-220-3 |
| Supplier Device Package | TO-220AB |
