CSD17573Q5B

Part Number
CSD17573Q5B
Manufacturer
Texas Instruments
Category
Transistors
Description
MOSFET N-CH 30V 100A 8VSON
CSD17573Q5B Specifications
RoHS No RoHS Information
EDA/CAD Models CSD17573Q5B PCB Footprint and Symbol
Warranty Up to 1 year [Limited-Warranty]*
Brand Texas Instruments
Product Line Semiconductors
Subcategory FETs, MOSFETs - Single
Series NexFET™
FET Type N-Channel
Technology MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss) 30V
Current - Continuous Drain (Id) @ 25°C 100A (Ta)
Drive Voltage (Max Rds On, Min Rds On) 4.5V, 10V
Rds On (Max) @ Id, Vgs 1mOhm @ 35A, 10V
Vgs(th) (Max) @ Id 1.8V @ 250µA
Gate Charge (Qg) (Max) @ Vgs 64nC @ 4.5V
Vgs (Max) ±20V
Input Capacitance (Ciss) (Max) @ Vds 9000pF @ 15V
FET Feature -
Power Dissipation (Max) 3.2W (Ta), 195W (Tc)
Operating Temperature -55°C ~ 150°C (TJ)
Mounting Type Surface Mount
Supplier Device Package 8-VSON-CLIP (5x6)
Package / Case 8-PowerTDFN
Quick Inquiry
In Stock25345 - More on Order
Quote LimitNo Limit
Lead-TimeTo be Confirmed
Minimum1
