FNB80560T3
| Part Number | FNB80560T3 |
| Manufacturer | ON Semiconductor |
| Category | Power Management ICs |
| Description | IC MTR DRVR 14V-16.5V SPMFA-A25 |
FNB80560T3 Specifications
| RoHS | No RoHS Information |
| EDA/CAD Models | FNB80560T3 PCB Footprint and Symbol |
| Warranty | Up to 1 year [Limited-Warranty]* |
| Brand | ON Semiconductor |
| Product Line | Semiconductors |
| Subcategory | Motor Drivers, Controllers |
| Series | Motion-SPM® |
| Motor Type - Stepper | - |
| Motor Type - AC, DC | Brushless DC (BLDC) |
| Function | Driver - Fully Integrated, Control and Power Stage |
| Output Configuration | Half Bridge (6) |
| Interface | Logic |
| Technology | IGBT |
| Step Resolution | - |
| Applications | General Purpose |
| Current - Output | 5A |
| Voltage - Supply | 14V ~ 16.5V |
| Voltage - Load | 400V (Max) |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Mounting Type | Through Hole |
| Package / Case | 25-DIP Module |
| Supplier Device Package | SPMFA-A25 |
Quick Inquiry
| In Stock | 517 - More on Order |
| Quote Limit | No Limit |
| Lead-Time | To be Confirmed |
| Minimum | 1 |
