| RoHS |
No RoHS Information
|
| EDA/CAD Models |
FP25R12W1T7B11 PCB Footprint and Symbol |
| Warranty |
Up to 1 year [Limited-Warranty]* |
| Brand |
Infineon Technologies |
| Product Line |
Semiconductors |
| Subcategory |
IGBTs - Modules |
| Series |
EasyPIM™ 1B |
| IGBT Type |
Trench Field Stop |
| Configuration |
Three Phase Inverter |
| Voltage - Collector Emitter Breakdown (Max) |
1200V |
| Current - Collector (Ic) (Max) |
25A |
| Power - Max |
20mW |
| Vce(on) (Max) @ Vge, Ic |
1.6V @ 15V, 25A (Typ) |
| Current - Collector Cutoff (Max) |
5.6µA |
| Input Capacitance (Cies) @ Vce |
4.77nF @ 25V |
| Input |
Three Phase Bridge Rectifier |
| NTC Thermistor |
Yes |
| Operating Temperature |
-40°C ~ 175°C |
| Mounting Type |
Chassis Mount |
| Package / Case |
Module |
| Supplier Device Package |
AG-EASY1B-2 |
