| RoHS |
No RoHS Information
|
| EDA/CAD Models |
IRFP250NPBF PCB Footprint and Symbol |
| Warranty |
Up to 1 year [Limited-Warranty]* |
| Brand |
Infineon Technologies |
| Product Line |
Semiconductors |
| Subcategory |
FETs, MOSFETs - Single |
| Series |
HEXFET® |
| FET Type |
N-Channel |
| Technology |
MOSFET (Metal Oxide) |
| Drain to Source Voltage (Vdss) |
200V |
| Current - Continuous Drain (Id) @ 25°C |
30A (Tc) |
| Drive Voltage (Max Rds On, Min Rds On) |
10V |
| Rds On (Max) @ Id, Vgs |
75mOhm @ 18A, 10V |
| Vgs(th) (Max) @ Id |
4V @ 250µA |
| Gate Charge (Qg) (Max) @ Vgs |
123nC @ 10V |
| Vgs (Max) |
±20V |
| Input Capacitance (Ciss) (Max) @ Vds |
2159pF @ 25V |
| FET Feature |
- |
| Power Dissipation (Max) |
214W (Tc) |
| Operating Temperature |
-55°C ~ 175°C (TJ) |
| Mounting Type |
Through Hole |
| Supplier Device Package |
TO-247AC |
| Package / Case |
TO-247-3 |
