| RoHS |
No RoHS Information
|
| EDA/CAD Models |
MAX4614CUD PCB Footprint and Symbol |
| Warranty |
Up to 1 year [Limited-Warranty]* |
| Brand |
Maxim Integrated |
| Product Line |
Semiconductors |
| Subcategory |
Analog Switches, Multiplexers, Demultiplexers |
| Series |
- |
| Switch Circuit |
SPST - NO |
| Multiplexer/Demultiplexer Circuit |
1:1 |
| Number of Circuits |
4 |
| On-State Resistance (Max) |
10Ohm |
| Channel-to-Channel Matching (ΔRon) |
200mOhm |
| Voltage - Supply, Single (V+) |
2V ~ 5.5V |
| Voltage - Supply, Dual (V±) |
- |
| Switch Time (Ton, Toff) (Max) |
12ns, 10ns |
| -3db Bandwidth |
70MHz |
| Charge Injection |
6.5pC |
| Channel Capacitance (CS(off), CD(off)) |
5pF, 5pF |
| Current - Leakage (IS(off)) (Max) |
1nA |
| Crosstalk |
-96dB @ 100kHz |
| Operating Temperature |
0°C ~ 70°C (TA) |
| Package / Case |
14-TSSOP (0.173", 4.40mm Width) |
| Supplier Device Package |
14-TSSOP |
