PCA9536D
| Part Number | PCA9536D |
| Manufacturer | Texas Instruments |
| Category | Interface ICs |
| Description | IC I/O EXPANDER I2C 4B 8SOIC |
PCA9536D Specifications
| RoHS | No RoHS Information |
| EDA/CAD Models | PCA9536D PCB Footprint and Symbol |
| Warranty | Up to 1 year [Limited-Warranty]* |
| Brand | Texas Instruments |
| Product Line | Semiconductors |
| Subcategory | I/O Expanders |
| Series | - |
| Number of I/O | 4 |
| Interface | I²C, SMBus |
| Interrupt Output | No |
| Features | POR |
| Output Type | Push-Pull |
| Current - Output Source/Sink | 10mA, 25mA |
| Clock Frequency | 400kHz |
| Voltage - Supply | 2.3V ~ 5.5V |
| Operating Temperature | -40°C ~ 85°C |
| Mounting Type | Surface Mount |
| Package / Case | 8-SOIC (0.154", 3.90mm Width) |
| Supplier Device Package | 8-SOIC |
