| RoHS |
No RoHS Information
|
| EDA/CAD Models |
TLP250H(F) PCB Footprint and Symbol |
| Warranty |
Up to 1 year [Limited-Warranty]* |
| Brand |
Toshiba Semiconductor and Storage |
| Product Line |
Semiconductors |
| Subcategory |
Optoisolators - Logic Output |
| Series |
- |
| Number of Channels |
1 |
| Inputs - Side 1/Side 2 |
1/0 |
| Voltage - Isolation |
3750Vrms |
| Common Mode Transient Immunity (Min) |
40kV/µs |
| Input Type |
DC |
| Output Type |
Push-Pull, Totem Pole |
| Current - Output / Channel |
2.5A |
| Data Rate |
- |
| Propagation Delay tpLH / tpHL (Max) |
500ns, 500ns |
| Rise / Fall Time (Typ) |
50ns, 50ns |
| Voltage - Forward (Vf) (Typ) |
1.57V |
| Current - DC Forward (If) (Max) |
20mA |
| Voltage - Supply |
10V ~ 30V |
| Operating Temperature |
-40°C ~ 125°C |
| Mounting Type |
Through Hole |
| Package / Case |
8-DIP (0.300", 7.62mm) |
| Supplier Device Package |
8-DIP |
