TPS7A3301RGWR
| Part Number | TPS7A3301RGWR |
| Manufacturer | Texas Instruments |
| Category | Power Management ICs |
| Description | IC REG LINEAR NEG ADJ 1A 20VQFN |
TPS7A3301RGWR Specifications
| RoHS | No RoHS Information |
| EDA/CAD Models | TPS7A3301RGWR PCB Footprint and Symbol |
| Warranty | Up to 1 year [Limited-Warranty]* |
| Brand | Texas Instruments |
| Product Line | Semiconductors |
| Subcategory | Voltage Regulators - Linear |
| Series | - |
| Output Configuration | Negative |
| Output Type | Adjustable |
| Number of Regulators | 1 |
| Voltage - Input (Max) | -36V |
| Voltage - Output (Min/Fixed) | -1.18V |
| Voltage - Output (Max) | -33V |
| Voltage Dropout (Max) | 0.8V @ 1A |
| Current - Output | 1A |
| Current - Quiescent (Iq) | 100µA |
| Current - Supply (Max) | 950µA |
| PSRR | 72dB (10kHz) |
| Control Features | Enable, Soft Start |
| Protection Features | Over Current, Over Temperature |
| Operating Temperature | -40°C ~ 125°C |
| Mounting Type | Surface Mount |
| Package / Case | 20-VQFN Exposed Pad |
| Supplier Device Package | 20-VQFN (5x5) |
