TPS7A3701DRVR PCB Footprint and Symbol |
| Warranty |
Up to 1 year [Limited-Warranty]* |
| Brand |
Texas Instruments |
| Product Line |
Semiconductors |
| Subcategory |
Voltage Regulators - Linear |
| Series |
- |
| Output Configuration |
Positive |
| Output Type |
Adjustable |
| Number of Regulators |
1 |
| Voltage - Input (Max) |
5.5V |
| Voltage - Output (Min/Fixed) |
1.2V |
| Voltage - Output (Max) |
5.37V |
| Voltage Dropout (Max) |
0.2V @ 1A |
| Current - Output |
1A |
| Current - Quiescent (Iq) |
400µA |
| Current - Supply (Max) |
1.3mA |
| PSRR |
58dB ~ 37dB (100Hz ~ 10kHz) |
| Control Features |
Enable |
| Protection Features |
Over Current, Over Temperature, Reverse Polarity, Under Voltage Lockout (UVLO) |
| Operating Temperature |
-40°C ~ 125°C |
| Mounting Type |
Surface Mount |
| Package / Case |
6-WDFN Exposed Pad |
| Supplier Device Package |
6-SON (2x2) |
